Description

Model

Width (mm)

Height (mm)

Depth (mm)

Display Area (W x D)mm

Temp Range (°c)

Power (w)

Weight (kg)

Voltage

Energy Consumption

Refrigerant

Auto Defrost

RRP

ROTA100WD

1070

1220+/-10

830

974 x 560

+1/+10

227

110

230/50HZ

3.8 (kWh/24h)

R134a

Yes

£2451

ROTA130WD

1310

1220+/-10

830

1214 x 560

+1/+10

239

130

230/50HZ

3.8 (kWh/24h)

R134a

Yes

£2706

ROTA150WD

1510

1220+/-10

830

1414 x 560

+1/+10

347

150

230/50HZ

5.6 (kWh/24h)

R134a

Yes

£3108

ROTA170WD

1710

1220+/-10

830

1614 x 560

+1/+10

355

170

230/50HZ

5.7 (kWh/24h)

R134a

Yes

£3349

ROTA200WD

2050

1220+/-10

830

1954 x 560

+1/+10

355

190

230/50HZ

5.7 (kWh/24h)

R134a

Yes

£3870

ROTA250WD

2520

1220+/-10

830

2434 x 560

+1/+10

543

220

230/50HZ

8.7 (kWh/24h)

R404a/R507

Yes

£4768

Optional Extras

Optional Extras:

303

20mm Grey granite worktop (per meter)

£100

1201

Moveable partition (low glass stand) (per meter)

£100

3002

Castors (per meter)

£300

1202

Fixed partition (hihg glass on decking)

£120

5002

Different front panel colour (per meter)

£100

321

Electronic temp. recorder, software & wire

£170

5003

Different base panel (per meter)

£30

816

Illuminated front panel with squares (per meter)

£360

Colors

black structure white structure black white  brown dark grey light grey blue green red orange yellow cappucino silver gold transparent
Black

Structure

White Structure Black * White * Brown Dark Grey Light Grey Blue Green Red Orange Yellow Cappucino Silver Gold Transparent
Colour of

metal parts –

front

RAL 9005 RAL 9003 RAL 9005 RAL 9003 RAL 8014 RAL 7031 RAL 7001 RAL 5005 RAL 6029 RAL 3020 RAL 1018 RAL 9006 IG 01
plastic fenders

colors

OD 05 OD 06 OD 04 OD 02 OD 01 OD 03
Plastic price

stripes colors

LCP 08 LCP 02 LCP 05 LCP 03 LCP 01 LCP 06 LCP 04 LCP 07
plastic sides

colors

AB 03 AB 02 AB 01 AB 04 AB 05
Anodized

Aluminum

Profiles Colors

AL 02 AL 01

Downloads

Manual:
