Description

Model

Width (mm)

Height (mm)

Depth (mm)

Display Area (W x D)mm

Temp Range (°c)

Power (w)

Weight (kg)

Voltage

Energy Consumption

Refrigerant

Auto Defrost

RRP

ROTA100

1070

1220+/-10

830

974 x 485

+1/+10

247

110

230/50HZ

3.5 (kWh/24h)

R134a

Yes

£2166

ROTA130

1310

1220+/-10

830

1214 x 485

+1/+10

248

130

230/50HZ

3.5 (kWh/24h)

R134a

Yes

£2403

ROTA150

1510

1220+/-10

830

1414 x 485

+1/+10

251

150

230/50HZ

3.5 (kWh/24h)

R134a

Yes

£2782

ROTA170

1710

1220+/-10

830

1614 x 485

+1/+10

312

170

230/50HZ

4.4 (kWh/24h)

R134a

Yes

£3028

ROTA200

2050

1220+/-10

830

1954 x 485

+1/+10

312

190

230/50HZ

4.4 (kWh/24h)

R134a

Yes

£3369

ROTA250

2520

1220+/-10

830

2434 x 485

+1/+10

341

220

230/50HZ

4.8 (kWh/24h)

R404a/R507

Yes

£4293



Optional Extras

Optional Extras:

3002

Castors (per meter)

£300

321

Electronic temp.recorder, software and wire

£170

5002

Different front panel colour (per meter)

£100

1202

Fixed partition (high glass on decking)

£120

1201

Moveable partition (low glass on stand)

£100

303

20mm Grey granite worktop (per meter)

£100

5003

Different base panel colour (per meter)

£30

816

Illuminated front panel with squares (per meter)

£360

Colors

black structure white structure black white  brown dark grey light grey blue green red orange yellow cappucino silver gold transparent
Black

Structure

White Structure Black * White * Brown Dark Grey Light Grey Blue Green Red Orange Yellow Cappucino Silver Gold Transparent
Colour of

metal parts –

front

RAL 9005 RAL 9003 RAL 9005 RAL 9003 RAL 8014 RAL 7031 RAL 7001 RAL 5005 RAL 6029 RAL 3020 RAL 1018 RAL 9006 IG 01
plastic fenders

colors

OD 05 OD 06 OD 04 OD 02 OD 01 OD 03
Plastic price

stripes colors

LCP 08 LCP 02 LCP 05 LCP 03 LCP 01 LCP 06 LCP 04 LCP 07
plastic sides

colors

AB 03 AB 02 AB 01 AB 04 AB 05
Anodized

Aluminum

Profiles Colors

AL 02 AL 01

Downloads

Manual:
